The patented Klo-Shure 8-Series Insulation Clamps allow insulated copper tube lines to be secured by inserting into the anchor channel and locking the top. No metal clamps needed.

Tubing supported and secured by internal part design. Elastomeric insulation is to be inserted inside coupling with insulation contacting the internal wall. Secondary operations are not needed. Entire assembly can be assembled or disassembled with a single hand or power wrench.

Key Features

  • UL Classified 2043 (25/50) for use in plenums and air handling systems.
  • Superior vapor barrier at suspension points.
  • Three times faster installation of closed-cell or elastomeric insulation than traditional methods.
  • Dramatically improved finished appearance of insulated tubing.
  • Eliminates insulation compression.
  • Single piece product.
  • Installs in seconds.
  • Dramatically improved finished appearance of insulated tube runs.
  • No Metal Clamps.
  • Available for 1/2" to 2-5/8" O.D. tube.
  • Insulation wall thickness sizes include 1/2"; 3/4" and 1".
  • Molded with high strength Thermoplastic Olefin (TPO) with UV-Rated Additive.
  • Temperature rating: -60F to +225F.
  • Made in the U.S.A.

Use Recommendations

  1. Maintains thermal vapor barrier.
  2. Properly supports pipe and tube.
  3. Overwrap of Klo-Shure coupling with insulation is not required.
  4. Recommended for horizontal installations only.

Klo-Shure 8-Series Insulation Clamp is a one-piece molded TPO plastic clamp. For use with elastomeric insulation.
